High Capacity Low Profile Weighbridge For Logistics And Transport

High Capacity Low Profile Weighbridge For Logistics And Transport

Product Details:
Place of Origin: China
Brand Name: SMARTWEIGH
Certification: ISO, CE
Model Number: SCS series
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiation
Packaging Details: Standard package
Delivery Time: 7-20 days
Payment Terms: T/T ; L/C; Wester Union,
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Platform Length: 6-30 Meters Plate: Smooth /checker
Platform Size: 3m X 3m To 4m X 6m (custom Sizes Available) Ramp Type: Concrete Work /carbon Steel
Display Type: Digital, LED/LCD Display (mounted Or Remote Options) Plate Thickness: 10/12/14mm
Power Supply: AC, DC (battery-operated) With Solar Panel Option Mounting Type: Surface-mounted, Pit-mounted, Or Portable Frame Options
Highlight:

Low Profile Weighbridge

,

High Capacity Weighbridge

,

Logistics Weighbridge

High-Capacity Low Profile Weighbridge for Logistics and Transport:


The High-Capacity Low Profile Weighbridge is a robust and efficient weighing solution specifically designed to meet the demanding

needs of the logistics and transportation industries. Engineered for durability, precision, and ease of installation, this weighbridge ensures

seamless vehicle weighing operations even under high-load and high-traffic conditions.


Key Features:

  • High Load Capacity

  • Low Profile Design

  • Modular Steel or Concrete Deck Options

  • High-Precision Load Cells

  • Corrosion-Resistant Finishing

  • Versatile Installation

  • User-Friendly Interface

  • Safety and Overload Protection

Applications:

  • Logistics hubs and distribution centers

  • Freight terminals and container yards

  • Truck weighing stations and toll booths

  • Industrial warehouses and manufacturing plants

  • Ports, rail yards, and airports


Specific requirements:


CLC Max Axle Load 30% Of Total Capacity Surface Checkered/ smooth
Material Q235B steel Top Plate Thickness 10mm/ 12mm/ 14mm
Color Customized Keyword Pitless truck Scale Weighbridge
Accuracy  1/6000 Plateform size 3m x 6m/12m/18m/24m
Surface finish Ball blasting and Anti-rust epoxy paint  Beam/ Ribs No 6 pcs
Power Supply AC 220V, DC 12V Battery Backup Load Cell Type Ball type load cell or Compression load cell
IP grade IP65-68  Certifications CE, RoHS, ISO etc
Calibration Digital calibration with built-in calibration weight


High Capacity Low Profile Weighbridge For Logistics And Transport
