Name: 22.5 Ton SWC515-A CS Weigh Module – Heavy-Duty Carbon Steel Compression Load Cell
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Weigh Module SWC515-A CS 22.5t
Availability: InStock

Home Products

22.5 Ton SWC515-A CS Weigh Module – Heavy-Duty Carbon Steel Compression Load Cell

Product Details:

Place of Origin:	CHINA
Brand Name:	Mettler Toledo
Model Number:	Weigh Module SWC515-A CS 22.5t

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	Mettler Toledo Load Cell	Maximum Capacity:	49,500 Lb (22,500 Kg)
Material:	Zinc Plated Steel	Metrology:	NTEP III 5,000d OIML C3
Load Cell:	12 M Cable SLC611	Accuracy:	Standard
Protection Rating:	IP68/69k	Environment / Material:	Normal / Carbon Steel
Hazardous Approval:	ATEX， FM	Criticality:	Standard
Highlight:	22.5 ton compression load cell , heavy-duty carbon steel weigh module , SWC515-A CS load cell

22.5 Ton SWC515-A CS Weigh Module – Heavy-Duty Carbon Steel Compression Load Cell

Product Overview

A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers, or structural beams. These modules are typically used in multiples under large platform scales such as truck and railroad track scales, as well as in tank, hopper, and silo weighing applications.

Key Features

Multi-Purpose Design

Suitable for static & dynamic tanks, hoppers, mixers, and conveyors. Features a high-accuracy, fully approved stainless hermetic load cell for all applications.

Enhanced Safety

Includes mechanical safety features (360° self-checking, lift-off & down-stops protections), hazardous approvals, and IP68-rated load cells for reliable operation.

Easy Installation

Features SafeLock™ plates for fast, straightforward installation without damaging the load cell. Includes integrated space for hydraulic jack.

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	49,500 lb (22,500 kg)
Material	Zinc plated steel
Metrology	NTEP III 5,000d OIML C3
Load Cell	12 m cable SLC611
Accuracy	Standard
Protection Rating	IP68/69k
Environment / Material	Normal / Carbon Steel
Hazardous Approval	ATEX, FM
Criticality	Standard
