Name: 1.1t SWB605 Carbon Steel Weigh Module with C3 Precision EN1090 Approved Design
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Weigh Module SWB505 SS 10kg
Availability: InStock

Home Products

1.1t SWB605 Carbon Steel Weigh Module with C3 Precision EN1090 Approved Design

Product Details:

Place of Origin:	CHINA
Brand Name:	Mettler Toledo
Model Number:	Weigh Module SWB505 SS 10kg

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	Mettler Toledo Load Cell	Maximum Capacity:	2,500 Lb (1,100 Kg)
Material:	Zinc Plated Steel	Metrology:	OIML C3, NTEP III 5M
Accuracy:	Standard	Protection Rating:	IP68/69k
Environment / Material:	Normal / Carbon Steel	Hazardous Approval:	ATEX Cat. 3GD FM Division 2
Criticality:	Condition Monitoring
Highlight:	1.1t carbon steel weigh module , SWB605 precision weigh module , EN1090 approved load cell

1.1t SWB605 Carbon Steel Weigh Module with C3 Precision EN1090 Approved Design

Economic System Integration

Multipurpose weigh module provides the highest accuracy for both static and dynamic applications. Self-aligning rocker pin ensures repeatability.

Product Description

A compression weigh module designed so that its top plate and base plate compress when weight is applied. Can be attached directly to ground, piers or structural beams. Typically used in multiples under large platform scales such as truck and railroad track scales, and in tank, hopper and silo weighing.

Key Features

Static & Dynamic Weighing: Highest accuracy for both application types with self-aligning rocker pin
Safety & Protection: 360° checking, built-in anti-uplift and down stops, hazardous area approvals & IP68 stainless steel load cell
Easy Installation: Pre-aligned for installation with minimal lift required for load cell removal

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	2,500 lb (1,100 kg)
Material	Zinc plated steel
Metrology	OIML C3, NTEP III 5M
Accuracy	Standard
Protection Rating	IP68/69k
Environment/Material	Normal/Carbon Steel
Hazardous Approval	ATEX Cat. 3GD FM Division 2
Criticality	Condition monitoring
