Name: Heavy-Duty SWC615 Carbon Steel Load Cell Module with 90 Ton EN1090 Approved
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Weigh Module SWC615 PM CS 90t EN1090
Availability: InStock

Home Products

Heavy-Duty SWC615 Carbon Steel Load Cell Module with 90 Ton EN1090 Approved

Product Details:

Place of Origin:	CHINA
Brand Name:	Mettler Toledo
Model Number:	Weigh Module SWC615 PM CS 90t EN1090

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	Mettler Toledo Load Cell	Maximum Capacity:	198,000 Lb (90,000 Kg)
Material:	Zinc Plated Steel	Metrology:	OIML C3, NTEP III 5M
Accuracy:	Standard	Protection Rating:	IP68/69k
Environment / Material:	Normal / Carbon Steel	Hazardous Approval:	ATEX Cat. 3GD, FM Division 2, IEC Ex
Criticality:	Condition Monitoring	Load Cell:	POWERCELL PDX
Highlight:	90 ton carbon steel load cell , EN1090 approved load cell module , heavy-duty Mettler Toledo load cell

Heavy-Duty SWC615 Carbon Steel Load Cell Module with 90 Ton EN1090 Approved

Product Overview

A robust compression weigh module designed for direct attachment to ground, piers, or structural beams. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications. Available in capacities ranging from 3 kg to 300 tons.

Key Features

PowerMount System: Delivers unsurpassed accuracy, reliability, and predictive diagnostics without requiring high maintenance junction boxes
Enhanced Reliability: Protects your profits by ensuring accurate weighing day after day
Predictive Diagnostics: Continuously monitors scale performance to reduce operating costs
Safe by Design: Engineered for high accuracy in demanding industrial environments

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	198,000 lb (90,000 kg)
Material	Zinc plated steel
Metrology	OIML C3, NTEP III 5M
Accuracy	Standard
Protection Rating	IP68/69k
Environment/Material	Normal/Carbon Steel
Hazardous Approval	ATEX Cat. 3GD, FM Division 2, IEC Ex
Criticality	Condition monitoring
Load Cell	POWERCELL PDX
