Name: 2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Weigh Module SWB405 2200kg 5m CS
Availability: InStock

Home Products

2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable

Product Details:

Place of Origin:	CHINA
Brand Name:	Mettler Toledo
Model Number:	Weigh Module SWB405 2200kg 5m CS

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	Mettler Toledo Load Cell	Maximum Capacity:	5,000 Lb (2,200 Kg)
Material:	Powder Coated Carbon Steel	Metrology:	OIML C3, NTEP III 5M
Load Cell:	SLB415	Accuracy:	Standard
Protection Rating:	IP68， NEMA 6	Environment / Material:	Normal / Carbon Steel
Hazardous Approval:	ATEX, FM	Criticality:	Standard
Cable:	5 M
Highlight:	2200kg heavy-duty load cell , carbon steel weighing module , Mettler Toledo load cell with cable

2200kg SWB405 Weighing Module – Heavy-Duty Carbon Steel Load Cell with 5m Cable

Product Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	5,000 lb (2,200 kg)
Material	Powder Coated Carbon Steel
Metrology	OIML C3, NTEP III 5M
Load Cell	SLB415
Accuracy	Standard
Protection Rating	IP68, NEMA 6
Environment / Material	Normal / Carbon Steel
Hazardous Approval	ATEX, FM
Criticality	Standard
Cable	5 m

Product Description

A compression weigh module is designed so that its top plate and base plate will be squeezed toward each other when weight is applied to it, and it can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing. Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons.

Key Features

All Safety on Board: Offers all safety features, including anti-uplift protection, 360° checking and down-stop protection to ensure the safety of tank weighing.
Easy Integration: SafeLock™ feature is built into SWB405 MultiMount™ weigh modules to make installation easier with all components locked in ideal initial positions.
Reliable Weighing: The hermetically sealed SLB415 load cell with IP68 rating can meet most industrial requirements.

Technical Specifications

Material

Powder Coated Carbon Steel

Material No

30830614

Maximum Capacity

5,000 lb (2,200 kg)

Protection Rating

IP68, NEMA 6

Environment / Material

Normal / Carbon Steel

Hazardous Approval

ATEX, FM

Load Cell

SLB415

Accuracy

Standard

Metrology

OIML C3, NTEP III 5M
