Name: SLP332D-IOL Load Cell 200kg C3/5k Digital Weighing Sensor
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Load Cell SLP332D-IOL-200kg C3/5k
Availability: InStock

Home Products Mettler Toledo Load Cell

SLP332D-IOL Load Cell 200kg C3/5k Digital Weighing Sensor

Product Details:

Place of Origin:	CHINA
Brand Name:	Mettler Toledo
Model Number:	Load Cell SLP332D-IOL-200kg C3/5k

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	Mettler Toledo Load Cell	Maximum Capacity:	440 Lb (200 Kg)
Material:	Aluminum, Passivated	Metrology:	NTEP III 5,000d OIML C3
Accuracy:	Standard	Protection Rating:	IP67
Hazardous Approval:	ATEX, FM	Criticality:	Standard
Platform Size (LxW):	400 Mm X 400 Mm	Connectivity:	Integrated
Highlight:	200kg IO-Link load cell , digital weighing sensor C3 , Mettler Toledo load cell

SLP332D-IOL Load Cell 200kg C3/5k Digital Weighing Sensor

Product Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	440 lb (200 kg)
Material	Aluminum, passivated
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Hazardous Approval	ATEX, FM
Criticality	Standard
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Integrated

Product Overview

The SLP332D-IOL is a 200kg C3/5k IO-Link digital weighing sensor designed for industrial weighing applications.

Key Features

Integrated PLC connectivity via IO-Link interface
Quick installation with standard cables and connectors
Smart5™ alarms and condition monitoring
Factory calibrated for immediate startup

This compression weigh module is designed for direct attachment to ground, piers, or structural beams. When weight is applied, the top plate and base plate compress toward each other. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications.

Advanced Features

Direct PLC Connectivity: The SLP33xD-IOL load cells connect directly to any automation systems via IO-Link, eliminating the need for additional electronic units.

Smart5™ Technology: Continuous condition monitoring and alarms according to NAMUR NE 107 ensure higher machine uptime and increased productivity.
