Place of Origin: | CHINA |
Brand Name: | SMARTWEIGH |
Certification: | ISO/CE/SGS |
Model Number: | HWTS 7610 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiable |
Packaging Details: | Scales body with plastic film package, electronic parts with carton box |
Delivery Time: | 3-8 weeks |
Payment Terms: | LC,TT, Weston Union, MoneyGram |
Supply Ability: | 100 sets per month |
Max Axle Cap:: | 10-40T | Verification Scale Value: | 2-5Kg |
---|---|---|---|
Weighing Pads Sizes:: | 800x430x30mm | Rubber Ramps Size:: | 800x350mm |
Connection: | 10m Cable(according To User’s Requirement) | Work Temperature: | Weighing Platforms And Loadcells::-30℃-+60℃ |
Working Power: | DC/ AC Power With Built-in 6V/10AH Lead-acid Battery, | Weighing Mode: | Dynamic Or Static Weighing |
Weighing Speed: | ≤10km/h | GW / NW: | 120KG / 115KG |
Package: | Carton Boxes For Indicator, Aluminum Box For Axle Weighing Pads | ||
Highlight: | axle weighing scales,axle weights for trucks |
Overload of vehicles is important reason that accelerates traffic accidents cause. In order to provide a convenient accurate law enforcement means for traffic management departments, we developed Wire type Portable Truck Axle Scales, providing the powerful ways for traffic manage department in the implementation of effective transfinite overload management. In recent years, this system is upgrading continuously according to use experience and policy adjustment.
Specification of the portable axle truck scales:
Model | SCS-3196E2 |
Capacity | 10T/20T/30T/40T for axle load |
Weighing Pads dimension | 800x430x30mm |
Rubber Ramp dimension | 800x350mm |
Accuracy in Static | 0.1% F.S |
Accuracy in Dynaimic | 1.5%F.S(1-5Km/h),3-5%F.S(5-10km/h) |
Over load | 150%F.S |
Division/Accuracy | 2/5/10/20 kg |
Rated working temperature | -20℃ - 40 ℃ |
Power supply | Built-in 6V/10AH lead-acid battery, external DC power(7.5V/1AH or 12V/1A) |
Weighing speed | ≤10km/h |
Connection | 10m cable(according to user’s requirement) |
GW & NW | 125KG/ 115KG |
One set include | Four rubber ramps and two weighing pads |
Feutures and Advantages:
1. It is light for easy portable any where, much more convenient than traditional truck scales.
2. Aluminum alloy stable hand box in luxury outlook.
3. It can also use the cars power(cigarette lighter) supply and charging.
4. Multiple seal protection, water proof that it could be working in the rain.
5. Detect whether overrun automatically.
6. Clients can set many work modes that suitable for different road and traffic regulations.
7. High precision and fine dynamic detection performance.
8. Backlight LCD display, day and night visible clearly.
9. Full English characters display, her interface friendly.
10. Easily input contains integrity of the province, city car number.
11. Built-in micro printer, print the complete the tests bill.
12. Can store over 1300 cars inspection record (expended).
13. AC/DC, all time display battery capacity, which can maintain 40 hours, and powered off automatically.
14. The indicator can work independently and may upload examined data to computer at any time.
Service Terms:
1. Warranty: One year
2. Export port: EXW factory or FOB shanghai
3. Trade terms: EXW, FOB, C&F
4. Payment terms: 50% deposit, balanced before shipping.
5. Place of origin: China
6. Packing: Carton boxes for indicator, aluminum box for axle weighing pads.
7.Delivery time: stock for sell.
8. Certificate: ISO. CE
9. Production Avalability: 100 Sets per day
