Name: The Role of Checkweighers in Modern Manufacturing Lines
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: The Role of Checkweighers in Modern Manufacturing Lines
Availability: InStock

Home Products Automatic Checkweigher

The Role of Checkweighers in Modern Manufacturing Lines

Product Details:

Place of Origin:	CHINA
Model Number:	The Role of Checkweighers in Modern Manufacturing Lines

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contact Now

Detailed Product Description

Product:	The Role Of Checkweighers In Modern Manufacturing Lines	Food & Beverage:	Hygienic Design, High-speed (500+ Ppm)
Pharmaceuticals:	±0.01g Accuracy, GMP Compliance	Cosmetics:	Gentle Handling, Anti-static Belts
Logistics:	Barcode Integration, Multi-weight Zones	Capacity Range:	0.1g - 50kg
Accuracy:	±0.01g - ±5g	Weighing Speed:	100 - 800 Products/minute
Belt Width:	150mm - 600mm	Machine Length:	1200mm - 2500mm
IP Rating:	IP54 - IP69K	Minimum Detectable Deviatio:	0.1% - 3% Of Target Weight
Reject Accuracy:	±5ms Timing Precision	Communication Protocols:	PROFINET, Ethernet/IP, OPC UA
Data Output:	CSV, SQL, Cloud API	HMI Interface:	7" - 15" Touchscreen
Operating Temperature:	0°C - 50°C
Highlight:	Mettler Toledo checkweigher load cell , manufacturing line checkweigher equipment , industrial checkweigher with load cell

The Role of Checkweighers in Modern Manufacturing Lines

Checkweighers have become indispensable in modern manufacturing, ensuring product consistency, regulatory compliance, and operational efficiency. These precision instruments dynamically weigh products on production lines, providing real-time feedback to minimize waste, prevent underfills/overfills, and maintain quality standards across industries.

Key Functions of Checkweighers in Manufacturing

Quality Control & Compliance

Weight Verification: Ensures each product meets specified weight tolerances (±0.1g to ±5g, depending on application)
Regulatory Compliance: Adheres to standards like FDA, EU Weights & Measures Directive, and HACCP
Defect Detection: Identifies missing components, incorrect fill levels, or packaging errors

Process Optimization

Real-Time Feedback: Adjusts filling machines to reduce giveaway (excess product)
Statistical Process Control (SPC): Tracks trends to predict and prevent deviations
Reduction in Waste: Minimizes product recalls and rework by catching errors early

Cost Efficiency

Lower Giveaway Costs: Prevents overfilling, saving raw materials
Reduced Fines: Avoids penalties for non-compliant products
Labor Savings: Automates weight checks, reducing manual inspections

Technical Specifications

Capacity Range

0.1g - 50kg

Accuracy

±0.01g - ±5g

Weighing Speed

100 - 800 products/minute

Belt Width

150mm - 600mm

Machine Length

1200mm - 2500mm

IP Rating

IP54 - IP69K

Communication Protocols

PROFINET, Ethernet/IP, OPC UA

Data Output

CSV, SQL, Cloud API

HMI Interface

7" - 15" touchscreen

Operating Temperature

0°C - 50°C

Industry-Specific Features

Food & Beverage

Hygienic design, high-speed (500+ ppm)

Pharmaceuticals

±0.01g accuracy, GMP compliance

Cosmetics

Gentle handling, anti-static belts

Logistics

Barcode integration, multi-weight zones

Tag:

Contact Person: Mrs. Shirley

Tel: +86-15851932889

Fax: 86-519-68781609
